Opis produktu
ERNI 374380 - Board-to-Board & Mezzanine Connectors 50p 1/1.5mm R/A FML 2R SMT/THR DAUG CARD Data rate25 Gbit/s MOQ19szt
- Pitch: 2,54mm
- Operating Temperature: -55 °C - 125 °C
- Operating Life in Mating Cycles: ≥ 400
- Soldering Heat: ≤ 260 °C
- Number of Contacts: 160 (a + b + c + d + e)
- Number of Rows: 5
- Series: DIN 41612/IEC 60603-2
- Dielectric Strength 500 Vac
- Operating Current: ≤ 2 A (20°C)
- Insulation Resistance (Min.): 10 MΩ (100 Vdc)
- Contact Resistance (Max.): 20 mΩ
- Packing Unit 19 piece
- weight 0.039 kg
