Opis produktu
2SD1554 NPN, 600V, 3.5A TO-3P - NPN silicon triple diffused transistor (with damper diode) intended as Color TV horizontal deflection output
- Vceo- 600 V,
- VCBO - 1500V
- Ic- 3.5 A,
- t - VCE=10V, IE= 1A typ - 3Mhz
- hfe.- 8
- Pt - 40W
2SD1554 NPN, 600V, 3.5A TO-3P - NPN silicon triple diffused transistor (with damper diode) intended as Color TV horizontal deflection output
typ tranzystora: | NPN |
prąd kolektora: | 3A |
